QUICK-ROTAN MINI-STOP Q41MSII - 10.3 Maximum Speed Control; 10.4 Hardware Test Routine

10.3 Control of the maximum speed
a) Activate programming level B (see section 9.1.2.2 "programming level B")
b) Set to parameter 607
c) Check the parameter value <607> and make correction if necessary via keys L+ or L−
d) Deactivate programming level B (see section 9.1.2.2 "programming level B")
Q-41-MSII-2-EN 10.2 02-02-21
10.4 Hardware Test
Hardware Test is a check routine permitting to use the operator panel OC-TOP or the mini programming
panel MPF for testing various components of the drive system (control system) and of the machine
installation.
Activation of the „hardware test“ = „HW-Test“ routine
a) Activate programming level „B“ and call up parameter 797
b) Set <797> to I
c) Deactivate programming level „B“
d) Turn off mains switch S1
e) Wait for approx. 2 secs. to elapse, and turn on main switch S1 again.
Response: The display shows „HARDWARE TEST“ for approx. 2 secs.
indication OC-TOP: indication MPF:
After that, the display shows the first test block: Inputs.
All OC-TOP keys equipped with LEDs become bright
Survey of test blocks:
Test- Check indication OC-TOP indication MPF
Block
1 Inputs
2 Outputs
3 Speed control-
unit
4 Synchronizer
To call up the test blocks (advancing from test block to test block), use keys A+ and A- on the OC-TOP
or with the keys M+ / M- on the Mini Control Pannel (MCP) in front of the control box.
E-T THW SHA DR WARE T EST
0
1E0
0
1A0
0
GSW
0GIW
00
E0
1
0X1:5
A0
1
0X1:9
SW
G0
IWG 0
