QUICK-ROTAN MINI-STOP Q41MSII - Sewing Without Sewing Program (Manual Sewing)

8.1 Sewing without Sewing Program (manual Sewing)
8.1.1 Functional sequence 1 (<799> = 1) with stop after seam end (<603> = I)
Functions: chop at start
chop at end
chain vacuuming at start
chain vacuuming at end
thread tension release at start and at end
Switch condition of the keys at the OC-TOP:
Key T9 (P/M) off (dark)
Key T10 (T/E) off (dark)
Key T6 on (bright)
Key T7 on (bright)
Key T11 on (bright)
Key T12 on (bright)
Key T15 on (bright)
Fig. 8.1a
max
bright
dark
0
0
1
0
- 2
+12
1
0
1
0
Pedal
LS
n
(AB)
S 1
<540>
<537>
<541>
<545>
<543>
(CD)
S 2
<537>
* A1Outp.
* A5Outp.
* see electrical connections dia
g
ram pa
g
e 12.2
* A6Outp.
1
0
ML Motor runs
Thred tension releas
e
Chain vacuum
Chopper
* Outp. A8
HACK
KESAU
FSL
<542>
<105>
<112>
<110>
<112>
Light-barrier
Q-41-MSII-2-EN 8.3 02-02-21
