QUICK-ROTAN MINI-STOP Q41MSII - Page 12

Q-41-MSII-2-EN 8.4 02-02-21
8.1.2 Functional sequence 1 (<799> = 1) without stop after seam end (<603> = II)
Functions: chop at start
chop at end
chain vacuuming at start
chain vacuuming at end
thread tension release at start and at end
Switch condition of the keys at the OC-TOP:
Key T9 (P/M) off (dark)
Key T10 (T/E) off (dark)
Key T6 on (bright)
Key T7 on (bright)
Key T11 on (bright)
Key T12 on (bright)
Key T15 on (bright)
Fig. 8.1b
max
0
0
1
0
- 2
+12
1
0
1
0
n
(AB)
S 1
<537>
<541>
<541>
<543>
(CD)
S 2
< 537>
1
0
ML
HACK
KESAU
FSL
<542>
<105>
<112>
<110>
<112>
<540><540>
(AB)
S 1
bright
dark
Pedal
* A1Outp.
* A5Outp.
* see electrical connections diagram page 12.2
* A6Outp.
Motor runs
Thread tension release
Chain vacuum
Chopper
* Outp. A8
Light-barrier
LS
