QUICK-ROTAN MINI-STOP Q41MSII - Page 13

8.1.3 Functional sequence 2 (<799> = 2) with stop after seam end (<603> = I)
Functions: fast scissors at start
fast scissors at end
chain vacuuming at start
chain vacuuming at end
thread tension release at start and at end
Switch condition of the keys at the OC-TOP:
Key T9 (P/M) off (dark)
Key T10 (T/E) off (dark)
Key T6 on (bright)
Key T7 on (bright)
Key T11 on (bright)
Key T12 on (bright)
Key T15 on (bright)
Q-41-MSII-2-EN 8.5 02-02-21
Fig. 8.2a
max
bright
dark
0
0
1
1
0
0
- 2
12 D
Pedal
LS
n
(CD)
S 2
<105> <110>
1
0
(AB)
S 1
ML
KESAU
FSL
Motor runs
<540>
<542>
* Outp. A8
* . A5Outp
* . A6Outp
1
1
0
0
* . A1Outp
* . A10Outp
Fast scissors forward
Fast scissors backward
SSVW
SSRW
<112> <112>
<545>
* see electrical connections dia
g
ram pa
g
e 12.2
Thread tension release
Chain vacuum
