c) Programming of Cycles (Number of Sequences of Program) to Stacker ON, of Program x
Speed and of the Subsequent Program
Condition: Operation mode „programmed sewing“ is on, i.e. key T9 (P/M) is bright and key T10
(T/E) is dark, machine not sewing
Display showing
Cycle programming is made via the keys L+ (number increased) or L- (number decreased)
Programming of the speed for the program is made via key A+ (value increased) or A- (value decreased)
Programming of the subsequent sewing program is made via keys D+ or D-.
d) Programming of Functions
Functions for the program x are controlled via the functional keys
- T5 function change-over for keys T1 … T4 (shift key)
- T1 chain close-off (<425> = I)
- T5+T1 automatic change-over between program 1 and program 2 (see Item 8.2.2)
- T2 speed during programmed sewing:
variable (treadle-controlled) when T2 is dark
constant (automatic) when T2 is bright
- T5+T2 no function
- T3 blow chain at seam end
- T5+T3 light barrier start
- T4 no function
- T5+T4 piece counter on display
- T6 vacuum at start of seam
- T7 vacuum at end of seam
- T8 currently no function
- T11 chopper at start of seam
- T12 chopper at end of seam
- T13 presser foot position at sewing stop
- T14 presset foot position at end of seam
- T15 light barrier
Caution: After programming push key T5 till LED goes out
9.1.2 Parameter Programming
9.1.2.1 Programming Level A (Operator Level)
This level is used for programming control parameters which immediately affect the operation sequence.
These are the parameters for the following functions:
- Light barrier compensation stitches <111>
- Light barrier fade-out <112>
- Softstart <116>
- Stitches from start (photocell dark) to thread tension release off <540>
- Stitches from start (photocell dark) to vacuum off <541>
- Stitches from photocell clear to vacuum on <543>
- Seam start: stitches from photocell dark to stop <565>
cycles
3600 00 0 1/00 2
rated speed
subsequent sewig
program
Q-41-MSII-2-EN 9.3 02-02-21
