Q-41-MSII-2-EN 7.3 02-02-21
The control system is connected with the sewing machine/ sewing equipment via:
inputs (Ex), such as for keys, switches, proximity switches, monitors, and
outputs (Ax), such as for solenoids, solenoid valves, signal indicators.
Function of the inputs (Ex) and the outputs (Ax) in dependence on <799>
E/A Funktion
<799> = 1 <799> = 2 <799> = 3
E1: Chopper Fast scissors -
E4: Program-switch
over
E6: Light barriere Light barriere Light barriere
E13: Flip-Flop Fast scissors
A1: Chopper Fast scissors
forwards
A2: Flip-Flop Chaining-off finger
A3: Chain blowing Chain blowing Chain blowing
A4: Presser foot lift Presser foot lift Presser foot lift
A5: Chain vacuuming Chain vacuuming Chain vacuuming
A6: Thread tension Thread tension Thread tension
release release on
A7: Signal lamp
A8: Motor runs Motor runs Motor runs
A10: Fast scissors
backwards
A16: Count signal Count signal Count signal
