Quickie Attitude Directions For Use

ENGLISH
13
Attitude/Attitude Hybrid Rev.1.0
De-Docking: Fig.5.6 - Fig.5.10
WARNING!
The de-docking procedure should take place on an even
surface.
NOTE: De-docking follows the opposite sequence as
described for Docking.
• Lock the wheelchair brakes.
• Open the red locking levers, A.
• Push the add-on bike forward/upwards until the upper
docking connector has no contact with the front frame
of your wheelchair, B.
• Swing the upper docking connector upwards, C.
• Lower the add-on bike until the stand wheels and
castors have contact to the ground.
• Pull the red release lever by the handgrip, D.
• Pull the add-on bike downwards towards yourself until
the docking pins are totally disengaged.
• Hold this position and push the add-on bike forward
so that it is clear of your wheelchair, E.
Fig.5.6
A
Fig.5.8
C
Fig.5.9
D
Fig.5.7
B
Fig.5.10
E
