ENGLISH
40
Attitude/Attitude Hybrid Rev.1.0
Category ICR18650MG1
Battery type: Lithium ion
Rated capacity: 14.5 Ah
Rated voltage: 36.2 V
End-of-charge voltage 42 V
Total energy: 515 Wh
Maximum discharge current: 30 A
Ambient charging temperature: 0 °C to 40 °C
Ambient operating temperature: -20 °C to 60 °C
Ambient storage temperature: +10°C to +30°C
Number of cells: 50
Protection rating: IP54
Weight: Approximately 3.5 kg
NOTE: We reserve the right to modify the design and technology of our products to incorporate the latest developments.
Please retain this operating manual for future reference.
This operating manual is also available to download from our website www.neodrives.de.
Key Elements Overveiw:
Battery Motor
Battery (housing) 1 Motor cable connector 7
Key 2 Motor 8
Charger socket / motor connection 3
On/off button 4 Charging device
LED display 5 Charging cable connector 9
On the add-on bike
Battery slide rail 6
Fig.5.1
5.0 Technical Data
