Quickie Attitude - Battery Capacity Indicator

ENGLISH
44
Attitude/Attitude Hybrid Rev.1.0
Fig.7.4
2
4
b
c
d
e
Battery capacity indicator:
You can check the battery capacity at any time using the
LED display.
If the battery has not been used for more than 48 hours:
• Tap button [4].
• The battery is switched on, all LEDs (a – e) flash three
times.
• Tap button [4] again.
• Now the LEDs indicate the capacity of the battery as
shown in the following table.
• If the battery has been used in the past 48 hours:
• Tap button [4].
• Now the LEDs indicate the capacity of the battery as
shown in the following table.
Battery Charge
LED lights Steadily LED Flashes
