ENGLISH
23
Attitude/Attitude Hybrid Rev.1.0
Neodrive Components:
• Drive motor.
• Smart MMI (display) incl. dock.
• This operating manual.
Technical Data:
Drive
Range*: 120 km
Speed 25 km/h
Power rating (peak) 250 Watt (650 Watt)
Operating voltage 36 Volt
Rated torque 12 Nm
Peak torque 40 Nm
Level of efficiency 80 % (incl. electronics)
Control system performance electronics Integrated into the wheel hub
Cassette receiver commercially available Plug-in cassette, up to 10 times
Brake disc From 160 mm diameter
Torque receiver Variable torque supports can be adjusted to the dropout
Weight 4.36 kg (just the drive including plug and cable, without
brake disc, free wheel, cassette)
Smart MMI
Display control monochrome
Display diagonal, resolution 2.4 inch, 240 x 320 pixels
Dimensions sMMI without dock (W X L X H) 53 mm x 85 mm x 14 mm
Connectivity Micro-B 1.1 USB, 5 volts power supply, 500 mA
connection to PC with diagnosis and
parametrisation software
Mechanical / electrical contacting twist-to-lock mechanism, corrosion-protected contacts,
spring loaded
Illumination LED backlight, 70–350 cd/m²
Display screen Scratchproof, hardened acrylic glass screen
Weight of the sMMI (detached) 55 g
Smart MMI dock
Controller 23 mm inside diameter, 3 buttons (up, down, menu), hard
wired
Mounting plate Stem and handlebar mounting, angle can be adjusted in 10°
steps, height can be adjusted using spacers
Weight (incl. cable and remote control) 60 g
Entire system
Operating temperature - 20 °C to + 50 °C (below 0 °C recuperation or the braking
assistant is automatically deactivated)
Protection rating IP65
NOTE: (*) The range depends on the battery used and on the terrain and the prevailing travelling conditions. The
specified range can be achieved at optimum travelling conditions (for instance level terrain, recently charged batteries,
ambient temperature of 20 °C, smooth journey etc.), a driving power of 100 watts and a pedalling efficiency of 100 watts.
We reserve the right to modify the design and technology of our products to incorporate the latest developments. This
operating manual is available for download on our website www.neodrives.de. If you require a version that is written in a
larger font, contact our Alber Service Center.
2.0 Standard Scope of Delivery
