ENGLISH
46
Attitude/Attitude Hybrid Rev.1.0
Fig.7.8
9
3
b
c
d
e
a
Fig.7.9
Charging the battery:
Fully charge the battery before its first use. The battery
capacity upon delivery is generally 30%. The battery can
be charged at any capacity without adversely impacting
its service life. The battery achieves its maximum
service life when it is charged at an ambient temperature
of between 10 °C and 30 °C
Connecting the battery charger:
The battery [1] does not need to be removed from the
Attitude for charging, it can stay
where it is. Only the motor cable plug [9] needs to be
removed (see section 4.2). Then,
proceed as before.
•• Insert the plug [9] of the battery charger into the
socket [3] on the battery.
•• The two parts are correctly aligned and interlocked
automatically by means of a
Magnetic latch.
•• Carry out the charging process according to the
specifications in the charger operating manual. In
addition, follow the instructions on the charging process
given in section 2.3.
Before inserting the plug [6] in the socket [3],
ensure that both parts are clean and there are no
metallic particles on them. If you detect such
particles, use a dry and clean cloth to remove
them.
Charging process:
When charging the battery follow the instructions
of the charger operating manual.
Also observe the safety information and
precautions provided in section 6.
LED displays during the charging process:
The following table shows the LED display [5] of the
battery during charging.
Battery Charge
LED lights Steadily LED Flashes
Fully Charged 100%
