X8
Tricopter
Note Since there’s no voltage output from the flight controller, an extra BEC module needs to be connected
to power supply servo for this model frame
5.2.2 How to recognizing clockwise and counterclockwise propellers
The diagrams above show two types of propellers: clockwise (called pushers) and counterclockwise (called
pullers). Pusher propellers are often
marked with a P. However not all
propellers are marked and both types are
often available in either rotational
direction. Therefore, it is most reliable to
recognize the correct propeller type by its
shape as shown below. Note that the
propellers below have the edge with the
shallow consistent curve at the leading
edge in direction of rotation and the more
radical scalloped (and usually thinner
edge) as the trailing edge. You can use
these features to recognize propellers of the correct direction of rotation.
