RadioLink PIXHAWK - Radio Calibration

Radiolink Electronic Ltd
www.radiolink.com
16
And then click “OK” and move all RC sticks and switches to their extreme positions so the red bars hit the
limits.
If the red bars have not any change when you move the sticks, please check the receiver have connect
success or not, make sure the receiver (maybe R9DS) is output SBUS signal (the blue LED of R9DS means
work as SBUS signal). You can check if every corresponding red bar for every channel is work as below:
CH1: low position = roll (towards the left), up position= roll (towards the right).
CH2: low position =pitch(forward), up position =pitch(backwards).
CH3: low position =reduced speed, up position =speed up.
CH4: low position = yaw (towards the left), up position = yaw (towards the right).
