RadioLink RC4GS V2 User Manual

RadioLink Electronic Ltd
www.radiolink.com
6
II. RC6GS V2 Functions
2.1 Display on LCD Screen
When you power on the transmitter, LCD screen shows Model Name, Transmitter Name, Transmitter Voltage,
Steering Trim, Throttle Trim, Model Voltage, Subsidiary Model ID, Returned Signal.
Note The Subsidiary ID won’t display until the function is activated in the menu ID SEED.
The telemetry function of model battery voltage can only be realized with R7FG/R8F.
Model Name
The system can store the data for 10 models, model name will show on the LCD when you power on the
transmitter. Please make sure the model name is the right one that you want.
If the model name you chose is not corresponding with your model, the settings should be wrong.
Transmitter Voltage
In addition to the model, LCD can show the voltage of battery. When the voltage is lower than 4.6V, it would
Model Name
Subsidiary ID
Transmitter
Name
Transmitter Voltage
Model Voltage
(Telemetry of 2S-6S
battery)
Steering Trim
Throttle Trim

RadioLink RC4GS V2 Specifications

General

Channels	4
Frequency	2.4GHz
Model Memory	10 models
Failsafe	Yes
Gyro Sensitivity Adjustment	Yes
Channel Bandwidth	500KHz
Screen	LCD
Simulator	Yes
Model Type	Car, Boat
Display	LCD
Telemetry	Yes
Range	400m (open area)
Battery	4x AA (not included)
Spread Spectrum	FHSS
Operating Voltage	4.8V to 6.0V
Control Distance	400m
Weight	320g
Receiver	R6FG
Voltage Range	4.8V to 6.0V
Compatible Receivers	R6FG, R6F
Range (open area)	400m
Transmitter Power	Less than 20dBm
