RadioLink RC6GS V2 User Manual

RadioLink Electronic Ltd
www.radiolink.com
6
II. RC6GS V2 Functions
2.1 Display on LCD Screen
When you power on the transmitter, LCD screen shows Model Name, Transmitter Name, Transmitter Voltage,
Steering Trim, Throttle Trim, Model Voltage, Subsidiary Model ID, Returned Signal.
Note The Subsidiary ID won’t display until the function is activated in the menu ID SEED.
The telemetry function of model battery voltage can only be realized with R7FG/R8F.
Model Name
The system can store the data for 10 models, model name will show on the LCD when you power on the
transmitter. Please make sure the model name is the right one that you want.
If the model name you chose is not corresponding with your model, the settings should be wrong.
Transmitter Voltage
In addition to the model, LCD can show the voltage of battery. When the voltage is lower than 4.6V, it would
Model Name
Subsidiary ID
Transmitter
Name
Transmitter Voltage
Model Voltage
(Telemetry of 2S-6S
battery)
Steering Trim
Throttle Trim

RadioLink RC6GS V2 Specifications

General

Channels	6
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Failsafe	Yes
Frequency Band	2.4GHz ISM band
Modulation Mode	GFSK
Spreading Spectrum	FHSS
Operating Voltage	4.8-15V
Low Voltage Alert	Yes
Simulator	Yes
Antenna Length	106mm
Weight	346g
Display	LCD
Range	600m
Adjacent Channel Rejection	>38dB
Control Distance	600m
Receiver	R7FG
Screen	LCD
Model Type	Car/Boat
Voltage Range	4.8-15V
Compatible Receivers	R6FG, R7FG
