Mixing mode (MXMD)
OFF, MIX
Initial value: OFF
Select setup item"MXMD"by pressing“Dec(-)”or “Inc(+)” button, press “Enter “ button, the initial mixing
mode“OFF”will blink. Press“Dec(-)”or “Inc(+)”button to switch “OFF” to “MIX”, press “Enter” button, the
blinking “MIX” will stop blinking.
"OFF": Mixing proportional to master channel operation.
"MIX": Mixing by master channel another function considered.
(6) When ending setting, return to the initial screen by pressing “Exit” button twice.
PMIX02 setting is the same as the PMIX01.
Take a dual-engine model (eg. Tracked vehicle) as an setting example.
Working theory of tracked vehicles
1. RC Cars: One execute unite of radio controls a movement of a car (eg. Steering wheel to Ch1-Direction
to turn left/right). Every R/C channel operation and every execute unite of car is ONE TO ONE.
2. Dual-engine Models: Being dual-engine category, tracked vehicle has two motors and each track is
driven by each motor.
3. Mix Control: The throttle (a function) on R/C monitors two motors （ two execute unites) move
forward/backward simultaneously. That is, ONE TO TWO mix control. On the other hand, the turning of
steering wheel makes one motor forward while the other backward at the same time to achieve direction
turning. Same as ONE TO TWO mix control.
4. Dual Mix Control： As controlling dual-engine vehicles drive forward/backward and turn left/right, two mix
controls at the same time are needed. RADIOLINK RC6GS V2 V2 has two programmable mix controls.
Reverse Setup before Mix Control Setup
Before setting the mix controls, please check if the reverses working correctly by testing its wheel and
throttle. Take steering wheel-- left track (Ch1 on receiver) and throttle--right track(Ch2 one receiver) as
