RadioLink RC6GS V2 User Manual

RadioLink Electronic Ltd
www.radiolink.com
22
If turning the wheel right and the right track moves backward; Or turning the wheel left and the right track
moves forward, meaning the initial steering is reversed and needs to be set. Please refer to the “button
operation”and get into below interface to complete the setup.
* If the steering reverse is correct, skip this steering reverse setup.
After setting the throttle/ steering reverse, then mix control can be set.
Mix Control Setup
1. Throttle mix steering：Tracked vehicles moving forward/backward
As tracked vehicles moving forward/backward is controlled by throttle, throttle leads steering in the mix control.
That is, Master-Throttle, Slave-Steering. Please refer to the “button operation”and get into below interface to
complete the setup.
* Percentage value varies the speed;
”+”means Master and Slave move to same direction at the same time
Turn the wheel clockwise, the left track moves forward，the right track remains still
6 - Channel
Radio Control System
9. ACCEL
10. IDLUP
11. SUB-TRIM
12. REVESE
Enter
Exit
Dec(-)
Inc(+)
6 - Channel
Radio Control System
13. D/R
14. ATL
15. PMIX01
16. PMIX02
Enter
Exit
Dec(-)
Inc(+)
6 - Channel
Radio Control System
[PMIX01]
MXMD：ON
FWRD: +100% MST：TH
BRAK: +100% SLV：ST
Enter
Exit
Dec(-)
Inc(+)
Enter
Exit
Dec(-)
Inc(+)
6 - Channel
Radio Control System
[REVERSE]
ST : REV CH4:NOR
TH : NOR CH5:NOR
CH3: NOR CH6: NOR

RadioLink RC6GS V2 Specifications

General

Channels	6
Frequency	2.4GHz
Modulation	FHSS
Telemetry	Yes
Failsafe	Yes
Frequency Band	2.4GHz ISM band
Modulation Mode	GFSK
Spreading Spectrum	FHSS
Operating Voltage	4.8-15V
Low Voltage Alert	Yes
Simulator	Yes
Antenna Length	106mm
Weight	346g
Display	LCD
Range	600m
Adjacent Channel Rejection	>38dB
Control Distance	600m
Receiver	R7FG
Screen	LCD
Model Type	Car/Boat
Voltage Range	4.8-15V
Compatible Receivers	R6FG, R7FG
