A CONNECTOR DESCRIPTION
Onboard connector part numbers
Table 25. Onboard connector part numbers
Onboard connector Part number Description
CD-ROM header HDR-012L CNT, box/header, 1*4, DIP/2.54/M/
11.4*12.75, black, BRASS/PBT, protect.PBF
ATX power connector, 4-pin SKT-092L CNT,power-conn,2*2pin,DIP/M/3,5A/
250V,BRASS/LCP,With post,half
transpare,Au:15u-in
ATX power connector, 24-pin SKT-110 CNT, power-conn, 2*12pin, DIP/M/4.2,1A,
half transpare, BRASS/NYLON66,with post
Chassis intrusion jumper HDR-001L-2 Header 1X2 Pb-Free
Fan power header HDR-0027L Header 4 pin 0.1" straight lock Pb-Free
Front panel I/O header HDR-003-16 CNT, pin/header, 2*8, DIP/2.54/M, black,
brass/PBT
IDE connector HDR-018L 2X20 shrouded head IDE PC99 ( blue), Pb-
Free
Lithium cell holder BTR-006L Battery socket,Pb-Free
PCI slot SKT-BU-PCI SLOTS CNT, SLOT, PCI, 120pin, DIP/1.27, white,
continue pin/2.54, Tail Length:3.18mm,Gold
Flash
Memory sockets:
DIMM1, DIMM3
SKT-0151-Blue CNT,memory socket,DDRII
1.8V,240pin,DIP/1,modulelock/3.18,P-B/
NYLON66,blue,Au:11.2-in
Memory sockets:
DIMM2, DIMM4
SKT-0151L DDRII connector, CEDG, 240P, VT062ST
Pb-Free
PCI Express x1 slot SKT-0156L PCI Express connector, X2, 36pin,Pb-Free
PCI Express x4 slot SKT-0157L-1 CNT, slot, PCI express x4,64pin,DIP/
1,black,continuepin/2.3,P-B/PBT,Au:15u-
in,Hook-Less,Pb-Free
PCI Express x16 slot SKT-0152 CNT, slot, PCI express x16,164pin, DIP/
1,black,continuepin/2.3,Copper Alloy,G/F.
Pb-Free
PS/2 mouse and keyboard SKT-079L STACK Mini-DIN (K/M) PC99 Pb-Free
SATA header SKT-0169L SATA vertical DIP, 1.27MM pitch, Pb-Free
SMBus header HDR-021L IPMB connector, 4-PIN, 22436040, Pb-Free
S-Video connector MH11071-H9-4F S-video connector, Mini-DIN7
USB headers (internal) SKT-0256L USB connector, 1port,vertical,Pb-Free
