System resources
60
PCI bus topology
Dynamically assigned Four USB controllers (32 locations on a 32-byte boundary)
Dynamically assigned SMBus controller (16 locations on a 16-byte boundary)
Dynamically assigned LAN controller (4096 locations on a 4096-byte boundary)
Address (HEX) Description
Physical Device Bus Dev Fun AdSel Ints
Intel Q35 (GMCH) Host bridge /DRAM controller 0 Host 00 0 Internal
Host-PCI Express bridge 0 Hub Link 01 0 Internal
Integrated graphics device 0 Hub Link 02 0 Internal
Integrated graphics device 0 Hub Link 02 1 Internal
ICH9/ICH9DO (ICH) Intel high definition audio 0 Hub Link 27 0 Internal
PCI Express port 1 0 Hub Link 28 0 Internal
PCI Express port 2 0 Hub Link 28 1 Internal
PCI Express port 3 0 Hub Link 28 2 Internal
PCI Express port 4 0 Hub Link 28 3 Internal
PCI Express port 5 0 Hub Link 28 4 Internal
PCI Express port 6 0 Hub Link 28 5 Internal
USB UHCI controller 1 0 Hub Link 29 0 Internal
USB UHCI controller 2 0 Hub Link 29 1 Internal
USB UHCI controller 3 0 Hub Link 29 2 Internal
USB UHCI controller 4 0 Hub Link 29 3 Internal
USB 2.0 EHCI controller 0 Hub Link 29 7 Internal
PCI-to-PCI bridge 0 Hub Link 30 0 Internal
PCI Express PCI Express x16 graphics card 1 PCIE 0 0 External INTA
PCI Express x1 LAN 2 PCIE 0 0 External INTA
PCI Express x1 LAN 3 PCIE 0 0 External INTB
Not connected 4 PCIE 0 0 - -
Not connected 5 PCIE 0 0 - -
Not connected 6 PCIE 0 0 - -
Not connected 7 PCIE 0 0 - -
PCI bus Mini PCI socket 8 PCI 4 0 AD 20 INTA & INTB
PCMICIA controller TI PCI1510 8 PCI 5 0 AD 21 INTC
PCI to UART bridge EXAR
XR17D152
8 PCI 6 0 AD 22 INTD
Intel integrated LAN 8 PCI 7 0 Internal Disable
