RadiSys PL35Q - PCI Slot

A
Internal device connectors
53
PCI slot
Pin # Side B signal Side A signal
1-12V TRST#
2TCK +12V
3GND TMS
4TDO TDI
5+5V +5V
6+5V INTA#
7INTB# INTC#
8 INTD# +5V
9PRSNT1# Reserved
10 Reserved +3.3V (I/O)
11 PRSNT2# Reserved
12 CONNECTOR KEY
13 CONNECTOR KEY
14 Reserved 3.3Vaux
15 GND RST#
16 CLK +3.3V (I/O)
17 G N D G NT #
18 REQ# GND
19 +3.3V (I/O) PME#
20 AD[31] AD[30]
21 AD[29] +3.3V
22 GND AD[28]
23 AD[27] AD[26]
24 AD[25] GND
25 +3.3V AD[24]
26 C/BE[3]# IDSEL
27 AD[23] +3.3V
28 GND AD[22]
29 AD[21] AD[20]
30 AD[19] GND
31 +3.3V AD[18
32 AD[17] AD[16]
33 C/BE[2]# +3.3V
34 GND FRAME#
35 IRDY# GND
36 +3.3V TRDY#
37 DEVSEL# GND
