RadiSys PL35Q - Page 54

A
Connector Description
54
38 PCIXCAP STOP#
39 LOCK# +3.3V
40 PERR# SMBCLK
41 +3.3V SMBDAT
42 SERR# GND
43 +3.3V PAR
44 C/BE[1]# AD[15]
45 AD[14] +3.3V
46 GND AD[13]
47 AD[12] AD[11]
48 AD[10] GND
49 M66EN AD[09]
50 GND GND
51 GND GND
52 AD[08] C/BE[0]#
53 AD[07] +3.3V
54 +3.3V AD[06]
55 AD[05] AD[04]
56 AD[03] GND
57 GND AD[02]
58 AD[01] AD[00]
59 +3.3V (I/O) +3.3V (I/O)
60 ACK64# REQ64#
61 +5V +5V
62 +5V +5V
Pin # Side B signal Side A signal
