- 98 -
Cooperation with PUE 7.1, PUE 10 terminal
Format: NT CR LF
Response options:
ES CR LF
- command not understood (format error)
MASS FRAME
- response: mass value in a basic measuring unit
Response format:
1 2 3 4 5 6 7 8
9-18
19
20-22
23
24-32
33
34-36
37 38 39 40 41
42-43
44 45
N
T
space
stability marker
zero marker
range marker
digit marker
space
mass
space
mass unit
space
tare
space
tare unit
space
Hidden digits quantity
space
Balance status
space
Countdown prior to an
automatic adjustment
CR
LF
NT
- command
Stability marker
- [space] if stable, [?] if unstable
Zero marker
- [space] for any value but zero, [Z] for zero value
Range marker
- marker informing on range within which mass value is comprised: [space] I
range balance, [2] II balance, [3] III balance
Digit marker
[zero] no digit, [1] one digit marker, [2] two digits marker, [3] three digits
marker, [4] four digits marker, [5] five digits marker
Mass
10 characters for net mass given in adjustment unit (with dot and a floating-
point “-“ sign )
Mass unit
3 characters - left justification
Tare
9 characters with dot - right justification (when floating-point tare gets turned
off automatically then zero value is sent)
Tare unit
3 characters - left justification
Hidden digit
quantity
-
Number specifying quantity of hidden digits: [space] when no digits are hidden,
[1] when 1 digit is hidden, [2] when 2 digits are hidden, [3] when 3 digits are
hidden
Balance status
-
Number specifying balance status: [0] weighing, [1] pending adjustment start, [2]
balance adjustment
Countdown prior
to an automatic
adjustment
-
For status [1], given in seconds as time interval prior to an automatic adjustment
start, the value ranges between 30 - 01.
For the remaining statuses the value is 00.
Example:
NT CR LF
-
command sent form a computer
N T _ ? _ _ 0 _ _ _ _ _ - 5 . 1 1 3 _ g _ _ _ _ _ _ _ 0 . 0 0 0 _ g _ _ _0_1_28CR LF
- command carried out, response: mass value and remaining data where: _ - space
