Connect Power
Connect the power cord and any optional accessories.
Attach the transformer connector to the
24VAC POWER pin connection on the
terminal strip. (The connector is keyed to
t one way only.)
NOTE: DO NOT plug in the transformer
until you have completed and checked
all wiring connections. Also, do not
attempt to link two or more Controllers
together with a single transformer.
Plug the transformer into the wall socket.
NOTE: Do not plug the controller into a
socket that is controlled by a secondary
ON/OFF light switch or GFI outlet.
If an optional Wireless Sensor (not
included) is to be used, attach the
connector to the 24 VAC ACC. POWER
terminal connections on the terminal strip.
19
STP Plus Controller
