Table 1 - Watering Time Offsets
Cycles
Per Day
List of Available Watering Time Offsets (Hours)
for each Cycles Per Day button
2X +6 , +1, +2, +3, +4, +8, +9, +12
3X +4 +8 +3 +6
+1 +2 +6 +12
4X +3 +6 +9 +2 +4 +6
+1 +2 +3 +4 +8 +12

NOTE: Successive presses of a CYCLES PER DAY button
will cycle through the list of available osets. Examples
of multiple watering start times are provided in Table 2.
Display with a Watering Time Offset selected:
User-Selected Offset
 
Table 2 - Watering Start Times with Offsets
Cycles Offset 1st 2nd 3rd 4th
2X +3 8:00
AM 11:00 AM --
3X +4 +8 8:00
AM 12:00 PM 4:00 PM -
4X +2 +4 +6 12:00
PM 2:00 PM 4:00 PM 6:00 PM
8
STP Plus Controller
