Status Indicators
watch the video at raindrip.com/smart
Installation & Programming
22
SHUTDOWN
RAIN FORECAST
UNDOCKED
CONTROLLER
IN
LOW BATTERY
CODEZIP
ERROR
VALVE WIRES
CHECK
ERROR
❹
❸
❷
❶
❺
Status Indicator Notes
❶ UNDOCKED – The controller is "undocked" or not fully seated in
the docking station.
❷ LOW BATTERY – Indicates batteries are low and need to be
replaced. All programming and settings (except current time) will be
maintained during battery replacement.
❸ ZIP CODE ERROR – The entered zip code was not recognized.
See SETTINGS on page 12.
❹ ERROR CHECK VALVE WIRES – A wiring fault was detected
during watering of a specific zone. The specific zone number will
also be displayed. Check for shorted wires or faulty solenoid.
❺ SHUTDOWN RAIN FORECAST – The controller will not water
when this indicator is on. If an optional rain sensor / switch is used,
then this indicator will turn on when the rain sensor / switch detects a
rain event.
