Raindrip RSC600i - Programming Aid - Introduction

The following information will be needed for each Zone
1) The number of watering CYCLES per day.
2) The number of minutes (DURATION) per CYCLE.
3) Start time (START) for each watering CYCLE.
The example below illustrates how a watering schedule is transferred into the programming aid.
ZONE SU MO TU WE TH FR SA ODD EVEN DURATION START
1
20 MIN 4:00 A
2
30 MIN 6:00 P
3
4
2
FRONT LAWN
LOCATION:
0002
Odd / EvenSpecific Days of Week
2
Number of watering CYCLES per day
CYCLE
1
1
25
Programming Aid - Introduction
If watering on “Specific Days of Week”:
❶
ZONE 1:
❶ CYCLES (0, 1, 2, 3, or 4):
Water 2 times per day on Sunday, Tuesday, and Thursday
Water 1 time per day on Saturday
❷ DURATION:
Water 20 minutes on the first cycle (CYCLE 1)
Water 30 minutes on the second cycle (CYCLE 2)
❸ START:
Start first cycle (CYCLE 1) at 4:00 AM
Start second cycle (CYCLE 2) at 6:00 AM
❸
❷
