Programming Note
• The watering schedule reservation system adds a 5 minute buffer (no watering) at the end of each DURATION.
• In the example below for ZONE-1 / CYCLE-1; the DURATION = 20 minutes and START = 4:00 AM.
– The next available START time is: (4:00 AM + 20 min. + 5 min.) = 4:25 AM.
– This next available START time is used for ZONE-2 / CYCLE-1.
– This was repeated for ZONE-3 / CYCLE-1. Based on ZONE-2 / CYCLE-1 START time and DURATION, the
next available START time is: (4:25 AM + 45 min. + 5 min.) = 5:15 AM .
Programming Aid - Example
watch the video at raindrip.com/smart
27
Option 1 Example - WATER ON SPECIFIC DAYS OF WEEK
ZONE SU MO TU WE TH FR SA ODD EVEN DURATION START
1
20 MIN 4:00 A
2
30 MIN 6:00 P
3
4
1
45 MIN 4:25 A
2
60 MIN 6:35 P
3
4
1
10 MIN 5:15 A
2
10 MIN 10:00 A
3
10 MIN 7:40 P
4
10 MIN 10:00 P
2
02020
LOCATION:
BACK LAWN
2
FRONT LAWN
LOCATION:
4040
LOCATION:
4
3
00
FLOWER BEDS
0
20
002
Odd / EvenSpecific Days of Week
2
Number of watering CYCLES per day
CYCLE
1
1
❸
❷
❶
❶
❷
❸
