Overview
RSC600i
watch the video at raindrip.com/smart
Installation & Programming
5
❶ LCD Display – Displays status of the controller. (page 21-22)
❷ Navigation Pad – Used to select, change, and enter values.
• LEFT and RIGHT arrows to move left or right.
• UP and DOWN arrows to increase or decrease values.
• ENTER saves all values and advances to next screen.
❸ Settings – View or change DATE, TIME, ZIP CODE, and
WATERING DAYS option. (page 11-12)
❹ Edit Schedule – View or change the WATERING SCHEDULE. (page 13-16)
❺ Auto Run – Change operating mode to ON / SKIP / OFF. (page 17)
❻ Water Now – Manual watering Start / Stop. (page 18)
❼ A/C Power Connection – External power connection.
❽ Valve Solenoid Wire Terminals – Color coded quick connect terminals.
❾ Rain Sensor / Switch Terminals – For rain sensor / switch wiring
(optional). No additional programming required. (page 20)
❿ Reset – Stops watering; clears controller memory of any errors;
and returns controller to the idle state. DATE, TIME, ZIP CODE,
WATERING DAYS option, and WATERING SCHEDULE are not erased.
⓫ Removable Cover – To access SETTINGS, EDIT SCHEDULE, and RESET
buttons.
