Instruction Manual for CT 416 and 518 D & DX Series
© Copyright RAMSOND Corporation 2007 – All rights protected. Unauthorized reproduction, in part or whole prohibited.
®
TIG TORCH
1. TORCH BODY (CUT TORCH IS ALSO EQUIPPED WITH A HAND SWITCH)
2. Collet
3. Collet Body
4. Alumina Cup
5. Long Back Cap
6. Short Back Cap
WARNING
Before replacing the consumables of the torch make sure the machine is turned off and disconnected from the power
source.
CONSUMABLES ARE AVAILABLE FOR PURCHASE AT www.RAMSOND.com.
Page 16
