FX-1 (2N1) Control Settings
Dixell control XR60C-4N1F0 w/Red LED
Randell Control Settings FX-Series
XR60C-4N1F0 Freezer
Randel Part No. RF CNT0604
Code Locked NO Code
SET Thermostat set point -1 SET
HY Thermostat Differential (hysterisis) 2 HY
LS Lower Set Point -4 LS
US Upper Set Point 59 US
Ot Offset Room Temp 0 Ot
P2P 2nd Probe Present Y P2P
OE Evaporator Probe Calibration 0 OE
OdS Output delay @ Startup 0 OdS
AC Anti-Cycle Time (min off after cycle) 1 AC
CCt Comp Continuous time, (Fast Freeze) 3 CCt
COn Compressor ON time (probe failure) 5 COn
COF Compressor OFF (probe failure) 5 COF
CF °C /°F F CF
Lod Probe Displayed (P1 or P2) P1 Lod
rES Resolution 0.0°C (only °C) IN rES
tdF Defrost Type EL tdF
dtE Defrost Termination Temp 45 dtE
IdF Interval between Defrosts 12 IdF
ndF (Maximum) length of Defrost 30 ndF
dSd Start defrost delay 0 dSd
dFd Display during Defrost dEF dFd
dAd Max display delay after defrost 12 dAd
Fdt Drip time after defrost end 3 Fdt
dPo First defrost after startup Y dPo
dAF Defrost delay after Fast Freezing 0 dAF
FnC Fan Operating Mode o-n FnC
Fnd Fan Delay after Defrost 4 Fnd
Fct Fan Temperature Differential 0 Fct
FSt Fan Stop Temperature (coil temp) 65 FSt
ALc Alarm Configuration Ab ALc
ALU Alarm Upper (max alarm) 65 ALU
ALL Alarm Lower (minimum alarm) -10 ALL
ALd Alarm Delay (min) 90 ALd
dAO Alarm Delay at startup (hrs/.10min) 1.3 dAO
ilP Digital Input Polarity (Door Switch) OP ilP
ilF Digital Input Configuration dor ilF
did Digital Input Delay (Door Open) 10 did
nPS Switch Action 0 nPS
odC Compressor and Fan Status F_C odC
PbC Probe Selection PTC/NTC ntc PbC
dP1 Display Probe 1 (Room Probe) - dP1
dP2 Display Probe 2 (Coil Probe) - dP2
rEL Software Info - rEL
Ptb Software info - Ptb
bold = hidden Parameters
