FX-1 (2N1) Control Settings
Dixell control XR60CX-4N1F0 w/Blue LED
Randell Control Settings FX-Series Randell Control Settings FX-Series
DIXELL PART NUMBER XR60CX-4R0F1
2N1
SETTINGS
DIXELL PART NUMBER XR60CX-4R0F1
2N1
SETTINGS
RANDELL PART NUMBER RF CNT0707 RANDELL PART NUMBER RF CNT0707
CODE LOCKED NO. CODE CODE LOCKED NO. CODE
Prb READ PROBE - Prb
dAF DEFROST DELAY AFTER FAST FREEZING 0 dAF
rPr ROOM TEMPERATURE PROBE READING
READ
ONLY
rPr Fnc FANS OPERATING MODE O-N Fnc
Set SET POINT -1 Set Fnd FAN DELAY AFTER DEFROST 4 Fnd
PR1 USER VARIABLE PARAMETERS - PR1 Fct
DIFFERENTIAL OF TEMP. FOR FORCED
ACTIVATION OF FANS
0 Fct
Set SET POINT -1 Set
FSt FAN STOP TEMPERATURE 65 FSt
HY DIFFERENTIAL 2 HY
Fon FAN ON TIME WITH COMPRESSOR OFF 0 Fon
LS MINIMUM SET POINT -5 LS FoF FAN OFF TIME WITH COMPRESSOR OFF 0 FoF
US MAXIMUM SET POINT 59 US FAP PROBE SELECTION FOR FAN MANAGEMENT P2 FAP
Ot THERMOSTAT PROBE CALIBRATION 0 Ot
ALc TEMPERATURE ALARMS CONFIGURATION AB ALc
P2P EVAPORATOR PROBE PRESENCE Y P2P ALU MAXIMUM TEMPERATURE ALARM 65 ALU
OE EVAPORATOR PROBE CALIBRATION 0 OE
ALL MINIMUM TEMPERATURE ALARM -10 ALL
P3P THIRD PROBE PRESENCE N P3P AFH
DIFFERENTIAL FOR TEMPERATURE ALARM
RECOVERY
1 AFH
O3 THIRD PROBE CALIBRATION 0 O3 ALd TEMPERATURE ALARM DELAY 90 ALd
P4P FOURTH PROBE PRESENCE N P4P dAO
DELAY OF TEMPERATURE ALARM AT START
UP
1.3 dAO
O4 FOURTH PROBE CALIBRATION 0 O4 AP2
PROBE FOR TEMPERATURE ALARM OF
CONDENSER
NP AP2
OdS OUTPUT DELAY AT START UP 0 OdS AL2 CONDENSER FOR LOW TEMPERATURE ALARM -40 AL2
AC ANTI-SHORT CYCLE DELAY 1 AC
AU2 CONDENSER FOR HIGH TEMPERATURE ALARM 230 AU2
rtr P1-P2 PERCENTAGE OF REGULATION 100 rtr AH2
DIFFERENTIAL FOR CONDENSER
TEMPERATURE ALARM RECOVERY
4 AH2
CCt CONTINUOUS CYCLE DURATION 3 CCt AD2 CONDENSER TEMPERATURE ALARM DELAY 15 AD2
CCS SET POINT FOR CONTINUOUS CYCLE 0 CCS dA2
DELAY FOR CONDENSER TEMPERATURE
ALARM AT START UP
1.3 dA2
COn
COMPRESSOR ON TIME WITH FAULTY
PROBE
5 COn
bLL
COMPRESSOR OFF FOR CONDENSER LOW
TEMPERATURE ALARM
N bLL
COF
COMPRESSOR OFF TIME WITH FAULTY
PROBE
5 COF
AC2
COMPRESSOR OFF FOR CONDENSER HIGH
TEMPERATURE ALARM
N AC2
CF TEMPERATURE MEASUREMENT UNITS F CF
i1P DIGITAL INPUT POLARITY OP i1P
rES RESOLUTION IN rES i1F DIGITAL INPUT CONFIGURATION dor i1F
Lod PROBE DISPLAYED P1 Lod
did DIGITAL INPUT ALARM DELAY 10 did
rEd X-REP DISPLAY P rEd Nps
NUMBER OF ACTIVATIONS OF PRESSURE
SWITCH
0 Nps
dLy DISPLAY TEMPERATURE DELAY 0 dLy odc
COMPRESSOR AND FAN STATUS WITH DOOR
OPEN
F_C odc
dtr p1-p2 PERCENTAGE FOR DISPLAY 50 dtr rrd
REGULATION RESTART WITH DOOR OPEN
ALARM
Y rrd
tdF DEFROST TYPE EL tdF
HES DIFFERENTIAL FOR ENERGY SAVING 0 HES
dFP
PROBE SELECTION FOR DEFROST
TERMINATION
P2 dFP PbC KIND OF PROBE NTC PbC
dtE DEFROST TERMINATION TEMPERATURE 45 dtE
Adr SERIAL ADDRESS 1 Adr
IdF INTERVAL BETWEEN DEFROST CYCLES 8 IdF onF ON/OFF KEY ENABLING NU onF
NdF MAXIMUM LENGTH FOR DEFROST 35 NdF
dP1 ROOM PROBE DISPLAY - dP1
dSd START DEFROST DELAY 0 dSd
dP2 EVAPORATOR PROBE DISPLAY - dP2
dFd DISPLAYING DURING DEFROST DEF dFd
dP3 THIRD PROBE DISPLAY - dP3
dAd
MAXIMUM DISPLAY DELAY AFTER
DEFROST
12 dAd
dP4 FOURTH PROBE DISPLAY - dP4
Fdt DRAINING TIME 3 Fdt rSe REAL SET POINT - rSe
dPo FIRST DEFROST AFTER STARTUP Y dPo rEL SOFTWARE RELEASE - rEL
bold = hidden Parameters
Ptb MAP CODE - Ptb
