FX1- 4N1 Control Operation
ELECTRONIC CONTROL FEATURES AND OPERATIONS
Randell has attempted to preset the temperature control to ensure that your unit operates at an optimum
temperature, but due to varying ambient conditions, including elevation, food type and your type of
operation, you may need to alter this temperature.
FIGURE-A
Your FX1-4N1 Series Unit is equipped with an electronic temperature control. Figure A, above,
illustrates the control location on the front above the louvered panel. This control is a Dixell model
number XB570L with a blue LED display and stainless steel cover.
FIGURE-B
Figure B shows the control without the stainless steel cover and with the examples of the displayed
information available with this control. The Randell FX1-4N1 control will feature a blue LED display
in place of the red display shown in Figure B.
