FX1- 4N1 Control Settings con’t
RANDELL CONTROL SETTINGS FX1-4N1
DIXELL PART NUMBER XB570L-4R0F1
RANDELL PART NUMBER RF CNT0703
CODE LOCKED (CON'T) NO CODE
rrd REGULATION RESTART WITH DOOR OPEN ALARM NO rrd
d2F SECOND DIGITAL INPUT CONFIGURATION EAL d2F
d2P CONFIGURABLE DIGITAL INPUT POLARITY CL d2P
did TIME DELAY FOR DIGITAL INPUT ALARM 5 did
oA1 FIRST AUXILIARY RELAY CONFIGURATION (7-8) TNR oA1
oA2 FIRST AUXILIARY RELAY CONFIGURATION (1-2) C2 oA2
oA3 FIRST AUXILIARY RELAY CONFIGURATION (9-10) C2 oA3
2CH COMPRESSOR SETTING DURING THE HOLDING PHASE C1 2CH
OAt SECOND COMPRESSOR SWITCHING ON DELAY 0 OAt
OAS SET POINT FOR SECOND COMRESSOR -50 OAS
OAH DIFFERENTIAL FOR SECOND COMPRESSOR 1 OAH
Oai PROBE SELECTION FOR THE SECOND COMPRESSOR RP Oai
OSt AUXILIARY OUTPUT TIMER 0 OSt
OSS SETPOINT FOR AUXILIARY OUTPUT 0 OSS
OSH DIFFERENTIAL FOR AUXILIARY OUTPUT 1 OSH
OSi PROBE SELECTION FOR THE SECOND COMPRESSOR RP OSi
tdf DEFROST TYPE RE tdf
IdF INTERVAL BETWEEN DEFROST CYCLES 8 IdF
dtE DEFROST TERMINATION TEMPERATURE 47 dtE
NdF MAXIMUM LENGTH OF DEFROST 35 NdF
dFd TEMPERATURE DISPLAYED DURING DEFROST DEF dFd
Fdt DRIP TIME 6 Fdt
dAd DEFROST DISPLAY TIME OUT 12 dAd
FnC FANS OPERATING MODE DURING THE HOLDING PHASE O-N FnC
FSt FAN STOP TEMPERATURE 68 FSt
AFH DIFFERENTIAL FOR THE STOP TEMPERATURE AND FOR THE ALARM 1 AFH
Fnd FAN DELAY AFTER DEFROST 2 Fnd
ALU MAXIMUM TEMPERATURE ALARM 15 ALU
ALL MINIMUM TEMPERATURE ALARM 10 ALL
ALd TEMPERATURE ALARM DELAY 30 ALd
EdA TEMPERATURE ALARM DELAY AT END OF DEFROST 30 EdA
tbA SILENCING ALARM RELAY YES tbA
Adr ADDRESS FOR RS485 1 Adr
bUt BUZZER ACTIVATION AT THE END OF THE CYCLE 1 bUt
tPb TYPE OF PROBE NTC tPb
rEL RELEASE CODE - rEL
Ptb PARAMETER CODE - Ptb
