R&M CMX 007 - Page 19

CMX 007 Switch 1 ControlMaster®NXT 003 Switch 1
-1 -2 -3 -4 -1 -2 -3
0 1 0 1 0 1 1
0 1 1 0
0 1 1 1 0 0 1
1 0 0 0 0 0 0
1 0 0 1 1 1 1
1 0 1 0
1 0 1 1 1 1 0
1 1 0 0 1 0 1
1 1 0 1 1 0 0
1 1 1 0 1 0 0
1 1 1 1 0 1 0
Table 5. Motor nominal frequency = 35 Hz
CMX 007 Switch 1 ControlMaster®NXT 003 Switch 1
-1 -2 -3 -4 -1 -2 -3
0 0 0 0 0 1 0
0 0 0 1 0 0 0
0 0 1 0 0 1 1
0 0 1 1
0 1 0 0 1 1 0
0 1 0 1 0 1 1
0 1 1 0 0 0 1
0 1 1 1 1 1 1
1 0 0 0 0 1 0
1 0 0 1 1 1 1
1 0 1 0 1 0 1
1 0 1 1 1 0 0
1 1 0 0
