5.6 S4 Control mode and slowdown mode

Set the control mode (EP or MS control) and slowdown mode according to the following table:

Table 10. Control mode

CMX 007 Switch S4 ControlMaster®NXT 003 Switch S4

-1 -1 -2

0 1 1

1 0 1
