5 COMMISSIONING
Compare the DIP switch settings of the CMX 007 with the following tables and find the correct settings for the
ControlMaster®NXT 003 DIP switches.
5.1 Old inverter parameter settings
Write in the table below the old frequency converter DIP switch settings.
Table 1.
CMX 007 parameter settings.
Switch S1 Switch S2 Switch S3 Switch S4
-1 -2 -3 -4 -1 -2 -3 -4 -1 -2 -3 -4 -1 -2 -3 -4
5.2 Driving frequency table selection
The maximum and minimum driving frequencies depend on the nominal frequency of the motor. Use the
following table to determine which table should be used to set
Table 2. Driving Frequency table selection
CMX 007 Switch S4 Maximum Driving
Frequency Table
Minimum Driving
Frequency Table
-2 -3 -4
0 0 0 3 5
0 1 0
0 0 1
1 0 0 4 6
1 1 0
