R&M CMX 007 - Setting S2 Minimum Driving Frequency

CMX 007 Switch 1 ControlMaster®NXT 003 Switch 1
-1 -2 -3 -4 -1 -2 -3
1 1 0 1 0 1 0
1 1 1 0
1 1 1 1
5.4 S2 Minimum driving frequency
Set the minimum driving frequency according to the following tables:
Table 6. Motor nominal frequency = 100/120 Hz
CMX 007 Switch S2 ControlMaster®NXT 003 Switch S2
-1 -2 -3 -4 -1 -2 -3
0 0 0 0 1 1 0
0 0 0 1 0 0 0
0 0 1 0 1 0 0
0 0 1 1 0 0 0
0 1 0 0 1 1 1
0 1 0 1 0 0 0
0 1 1 0 0 0 1
0 1 1 1 1 0 1
1 0 0 0 1 1 1
1 0 0 1 1 0 1
1 0 1 0 0 1 0
1 0 1 1 1 1 1
1 1 0 0
1 1 0 1
1 1 1 0
1 1 1 1
R&M Materials Handling, Inc.
4501 Gateway Boulevard
Springfield, Ohio 45502
P.: (937) 328-5100
FAX: (937) 325-5319
20/28
R&M Materials Handling, Inc. reserves the right to alter or amend the above information without notice.
