1 INTRODUCTION
1.1 About this manual
This manual offers installation and commissioning instructions of CMX 007 frequency converter replacement to
ControlMaster®NXT 003 .
As a maintenance
technician, taking the time to read this manual will help you easily adopt the replacement
procedures. Note that this manual is not intended as a substitute for proper training.
1.2 About the upgrade kit usage
This upgrade kit is designed only for CMX 007 frequency converter which is mounted in a
TROLLEY MOTOR UNIT
(TMU) in chain hoist crane. It is not designed for wire rope hoist
application. There is a different replacement kit available for the Wire Rope Hoist application.
There is no replacement kit available for chain hoist hoisting application. In case of brake
down, the complete chain hoist must be replaced with a new one.
Parameters for the new ControlMaster®NXT 003 frequency converter have NOT BEEN SET
UP at the
factory. Please make sure that you SET UP the DIP switches according the
following instructions before start-up.
1.3 Waste treatment and recycling of removed material
The removed parts and packaging material shall be recycled according to local regulations. We recommend
recycling the frequency converter’s aluminum heat sink separately.
R&M Materials Handling, Inc.
4501 Gateway Boulevard
Springfield, Ohio 45502
P.: (937) 328-5100
FAX: (937) 325-5319
3/28
R&M Materials Handling, Inc. reserves the right to alter or amend the above information without notice.
