R&S LCX Series Getting Started

Instrument control
R&S
®
LCX Series
41Getting Started 1179.2254.02 ─ 03
Table 6-1: Instrument status bar
Indicator Description
Touchscreen
Indicates that the touchscreen is locked.
See "General instrument functions > User button" in the user
manual.
Virtual Network Computing
White indicates that the VNC service is enabled for remote
access over LAN.
See "Network and remote control > Connecting the R&S LCX for
remote access" in the user manual.
File Transfer Protocol
White indicates that the remote access to the file system over
LAN is enabled.
See "Network and remote control > Connecting the R&S LCX for
remote access" in the user manual.
(Remote control with SCPI
commands)
Indicates the status when working with remote control com-
mands:
●
single white flash:
SCPI command received successfully
●
red
A remote control error has occurred, entered in the SCPI
error queue
●
gray
no SCPI communication
Measurement mode
White indicates that the R&S LCX measures in continuous mea-
surement mode.
See "Instrument functions > Measurement mode" in the user
manual.
Trigger event
Flashes once on a trigger event.
Logging
Indicates the logging state:
●
white
Data logging is running.
●
red
A logging error has occurred.
●
gray
Logging is disabled
See "General instrument functions > Logging" in the user man-
ual.
USB host interface
White indicates that a connected USB memory device is in use.
See Chapter 3.8, "Connecting USB devices", on page 21.
