6.2.1.5 Signal parameters
Figure 6-2: Measurement signal parameters
Each softkey opens an on-screen keypad for setting the signal parameters
directly. Alternatively, you can use the corresponding settings keys at the front
panel.
6.2.1.6 Test signal monitor
Figure 6-3: Test signal monitor
The test signal monitor displays voltage and current results and the measurement
accuracy.
6.2.1.7 Measurement parameters and results
Figure 6-4: Measurement results window
Means of manual interaction
