Example:
*RST; :CALC:LIM:CONT 1 GHZ, 2 GHZ
Select a lin. frequency sweep (default) and define an upper limit
line segment in the stimulus range between 1 GHz and 2 GHz,
using default response values (–40 dB).
CALC:LIM:DISP ON
Show the limit line segment in the active diagram.
Manual operation: See "Segment List" on page 436
CALCulate<Chn>:LIMit:CONTrol:SHIFt <LimShift>
Shifts an existing limit line in horizontal direction. See also Chapter 9.4.1.1, "Rules for
limit line definition", on page 230.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Setting parameters:
<LimShift> Offset value for the limit line
Range: Virtually no restriction for limit segments
Default unit: NN
Example:
*RST; :CALC:LIM:CONT 1 GHZ, 2 GHZ
Define a limit line segment in the stimulus range between 1 GHz
and 2 GHz, using default response values.
CALC:LIM:CONT:SHIF 1; :CALC:LIM:CONT?
Shift the segment by 1 Hz. The modified limit line segment
ranges from 1000000001 (Hz) to 2000000001 (Hz).
Usage: Setting only
Manual operation: See "Shift Lines" on page 435
CALCulate<Chn>:LIMit:DATA <Type>, <StartStim>, <StopStim>, <StartResp>,
<StopResp>
Defines the limit line type, the stimulus and response values for a limit line with an arbi-
trary number of limit line segments. See Chapter 9.4.1.1, "Rules for limit line definition",
on page 230.
Note: In contrast to CALCulate<Chn>:LIMit:CONTrol[:DATA], this command
does not overwrite existing limit line segments. The defined segments are appended to
the segment list as new segments.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Type> Identifier for the type of the limit line segment:
0 – limit line segment off, segment defined but no limit check
performed.
1 – upper limit line segment
2 – lower limit line segment
