Fullcalibration
FullcalibrationdialogboxopensautomaticallyaftertheConfigurationwizardor
manually fromthemenuConfiguration→Fullcalibration.
Calibrationprocedure:
1. Inthedropdownlistthepreviouslyselected(inСonfigurationwizard)calibration
platesizeischosen.Compareittotheactualcalibrationfield,chooseitfromthe
list,ifneeded.Focaldistanceofthelensesisdetectedautomatically,andisonly
allowedtochangebytechnicalsupportspecialistwhencalibrationproblems
occur.
2. Inaccordancewiththetextpromptandsymbolimageinstallthe calibration plate
in thedesiredposition.Thebrightnessoftheimagesof calibration plate can be
adjusted withexposurecontroller.Youshouldnot allow very dark images or
images with excessivebrightnessareas.Press the Capture button. Original plate
position - theposition at the working distance from the scanner (marking on the
view from cameras matches the markers on the plate), the cross is projected on
the central marker.
3. Iftheplateplacementisincorrectaerrormessagewillappear.Correct the
placement and repeat the step.
