4 Unit transportation
Transporting unit with pallet:
x
Note required door width:
Appliance size 60 61 62 11 12 21 22
x [mm] 880 920 1120 920 1120 950 1150
x [Inch] 34 3/4 36 1/4 44 1/8 36 1/4 44 1/8 37 1/2 45 1/4
Transporting unit without pallet:
i
NOTICE
Risk of damage to the unit!
Only floor units may be transported without a
pallet using pallet truck.
Lay wooden beams underneath in grey area
(see arrow).
x
