Rational CombiMaster Plus series User Manual

63
13 Options
13 Options
Left and right heat shields (not suitable for Combi-Duo and UltraVent)
If it is not possible to keep the left side (or right,
on unit sizes 61 and 11) of the unit a sufficient
distance away from heat sources, an additional
heat shield can reduce thermal loads.
i
NOTICE
A clearance of 2” is still required from the heat
shield to the heat source.
50 mm [2“]
Appliance size 61 62 11 12 21 22
Left heat shield 60.70.390 60.70.392 60.70.391 60.70.393 60.70.394 60.70.395
Right heat shield 60.70.736 60.70.743

Rational CombiMaster Plus series Specifications

General

Type	Combi Oven
Material	Stainless Steel
Temperature Range	30°C to 300°C
Operating Modes	Steam, Combination
Capacity	10, 20, 40 liters (varies by model)
