Rational CombiMaster Plus series User Manual

18
5 Setting up the unit
5.2 Minimum distances
i
NOTICE
Unit overheating may cause material and unit
damage!
If the ambient temperature to the left of the
unit becomes too high, it may trigger an emer-
gency shutdown of the unit.
i
NOTICE
Unit overheating may cause material and unit
damage!
Do not install fryers to the rear of the unit.
i
NOTICE
Frost may cause unit damage!
Only install units in frost-proof rooms.
Minimum distance to walls
x
x
y
Appliance size 60 61 62 11 12 21 22
x [mm] 10 50 50 50 50 50 50
x [Inch] 1/2 2 2 2 2 2 2
y [mm] 10 50 50 50 50 500 500
y [Inch] 1/2 2 2 2 2 20 20
