Rational CombiMaster Plus series User Manual

39
6 Electrical connection
6.6 Voltage Conversion
208/240V units All electric units and 62/102/202 gas units are
set to 208V ex works. They can be converted to
240V.
To convert from 208V to 240V proceed as follows:
> Disconnect unit from mains
> Remove left side panel and open operator
panel.
> Set power switch S13 to desired voltage (208
or 240V)
> On the control transformer T1 change con-
nection to the desired voltage input (208 or
240V)
> In the starter kit of the unit there is a sticker
which has to be filled in after voltage conver-
sion. After filling it in put the sticker next to
the type plate.
60:

Rational CombiMaster Plus series Specifications

General

Type	Combi Oven
Material	Stainless Steel
Temperature Range	30°C to 300°C
Operating Modes	Steam, Combination
Capacity	10, 20, 40 liters (varies by model)
