NOTICE
In order to avoid hazards, the mains power
cable may only be replaced by the manufactur-
er, its customer service representative or simi-
larly qualified service personnel.
NOTICE
Non-functioning unit !
Tighten mains lead connection.
Use copper wire only for power supply connec-
tions of connect size.
Electrical units: Connect a supply cable of at least Type NEC UL
standard and tighten the mains lead connection.
Connect the cable according to the following
diagram:
Gray connector terminals:
L1, L2, L3 (independent of rotary field).
Yellow-green connector terminals: electrical
ground connection.
Gas units: Should the connection line need to be replaced
as part of service work, use a cable of quality no
less than SGO or SJTOW or equivalent (original
rating) 14-2 plus ground.
For plug type reference NEMA.
5-15P 120V IP for 61/101/201
6-15P 208/240V IP for 62/102/201
this is also an option on 61/101/201
