22
5 Setting up the unit
Condensation breaker This clearance space is sufficient to install a
condensation breaker so that exhaust air can be
directed into non-critical areas.
Other
NOTICE
Unit malfunction!
Avoid steam or grease sources near the cool-
ing air filter. Moisture intake may result in unit
malfunctions.
5.3 Securing the unit
5.3.1 Tabletop units
For safety reasons, tabletop units should only be
placed atop a manufacturer-original oven stand
or base unit. Maximum working height for the
topmost rack is 63” [1600 mm].
Unit size 60 These units do not have height-adjustable feet;
instead, they are set up directly on the installa-
tion surface.
The installation surface must be level, clean and
free of grease. Unevenness across the width of
the unit must be no greater than 0.04” [1 mm].
A sealant band is affixed to the underside of the
unit to seal the installation site. This prevents dirt
from getting underneath the unit. When moving
the unit, take care not to damage this seal.
Mounting onto an oven stand:
Insert the two included neoprene blind rivet nuts
into the holes in the rear part of the underbody.
Place the unit onto the oven stand.
Secure in place using the screws provided.
