21
5 Setting up the unit
Electric units: Recommended 10” (254 mm) clearance from
unobstructed rear vent pipes and any surface col-
lecting grease or flammable material.
LEFT SIDE VIEW
Electric unit
minimum
clearance 10“
If steam from the venting pipe cannot be direct-
ed into an exhaust hood or a ventilating ceiling,
there must be at least 20” [500 mm] clearance
space above the unit.
min. 20”
[500 mm]
min. 18”
[460mm]
