Rational CombiMaster Plus series User Manual

40
6 Electrical connection
61-22:
S 13
440/480 V units Units are set to 480V ex works, but can be con-
verted to 440V.
To convert from 480V to 440V proceed as follows:
> Disconnect unit from mains
> Remove left side panel and open operator
panel.
> Remove adapter cable W22 from input trans-
former T3 and plug X72.
> Connect plug X72 to transformer T3.
> Set power input switch S13 to 440 V

Rational CombiMaster Plus series Specifications

General

Type	Combi Oven
Material	Stainless Steel
Temperature Range	30°C to 300°C
Operating Modes	Steam, Combination
Capacity	10, 20, 40 liters (varies by model)
